Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: TOPBAND
  • Model Number: TB12300F-S103B
  • Type: LiFePO4, LiFePO4
  • Nominal Voltage: 12V
  • Size: 550*380*410mm, 550*380*410mm
  • Nominal Capacity: 300Ah
  • Model: TB12300F-S103B
  • Warranty: 2years
  • Weight: 68Kg
  • Application: Vehicle
  • Max discharge current: 350A
  • Max charge current: 100Amps
  • working voltage range: 9.2V~14.6V
  • LCD size: 3.5 inch

Packaging & Delivery

Packaging Details: Standard battery international package for different delivery
Delivery Detail: 10-15days

2017 New Lithium Battery 12V 300AH vechicle battery







TOPBAND Lithium Iron Phosphate (LiFePO4) vehicle battery is the ultimate in weight and size versus power technology. we design this battery mainly replacement for your Lead-acid battery and will require no change to your existing system. It can be placed that uses a sealed lead acid battery completely,which widely used for deep cycle or energy storrage system replacement lead acid batteries in UPS, Telecom, recreative vehicles, Marine, Solar etc.

LiFePO4 contains no poisonous meterial and does not create gasses during charge as traditional Lead-Acid batteries do. Compared to lead-acid, Lithium Iron Phosphate batteries are also extremely light, smaller, have much lower self-discharge, and are environmentally friendly.


TOPBAND Models have a Vehicle Battery Management System (BMS). BMS monitors the key operational parameters of each cell during charging and discharging such as voltages, currents and internal temperatures.

There are three main objectives common to all Battery Management Systems (BMS) are:



• Protect the cells or the battery from damage from overcharging or discharging too low.
• Prolong the life of the battery with cell balancing.
• Maintain the battery in a safe operating state.


Because of its light weight, safety, excellent thermal stability, good electrochemical properties and high specific capacity is this application of the material very well received.

Dimensions equal to the standard battery for direct replace.





BATTERY SPECIFICATION:



1. Itemspecification
2.Model:TB12300F-S103B
3.TypeLiFePO4
4.Normal voltage:12V
5.Normal capacity:300Ah
6.working voltage range:9.2V-14.6V
7.Max discharge current:350A
8.Max charge current:100A
9.size550*380*410mm
10.weight68Kg
11.LCD size3.5 Inch
12Communication interfaceCANBUS protocol
13Black housingWaterproof
14ApplicationVehicle



MAIN FEATURES:

  • Fast charge rate
  • Enables to utilize the narrow space in your equipments
  • Twice to four times the service life of lead-acid batteries
  • More lighter than lead acid battery light 1/5 on average
  • Rectangular battery packing boxes are made of steel which anti-piercing, extrusion and water-resistant
  • Each battery pack configured with individual battery management system to monitor and control output current, voltage and temperature of batteries
  • BMS installed in packing box compartment in order to prevent any physical damage to BMS when moving
  • Available in various sizes
  • Assembled with LCD display for batteries parameters, the LCD located positin is various.
  • Configured with communication interface- CANBUS protocol, can be contact with the commputer.
  • Environmentally friendly

SAFETY:



             Every battery packs have compact  the Battery Manage System (BMS), its mainly function are:

  •              Internal over charge protection
  •              Internal over discharge protection
  •              Internal short circuit protection
  •              Internal cells balance
  •              Internal temperature monitor
  •              No presence of toxic  substances



LIFETIME:

  • Expecting charge/discharge cycles number over 2,000.
  • Self-discharge rate about 2% per month
  • Except 8-10 years of battery life that will reduce your operating cost by half compare with Lead acid batteries.



CHARGING:

The TOPBAND energy storage battery is intended to be used as a direct replacement for lead acid batteries used in solar energy storage systems.  It is best for the battery not to be trickle charged but to use advanced chargers that turns OFF charging current when the battery is completley charged at 14.6V.  TOPBAND sells "Smart" chargers for lithium batteries.  Using lead acid chargers that charges up to 16V, if leaving them ON, will damage the Lithium battery over extended time.



 WARRENTY TIME:



       2 Years Full Replacement Warranty including battery and charger.



NOTE:

This batteries are to be used for energy storage applications and NOT for engine starting applications.Unlimited packs in parallel at 12V
