TOPBAND 12V 100Ah Lifepo4 battery for Marine / Caravan

FOB Reference Price:Get Latest Price
US $400-550 / Pieces | 1 Piece/Pieces 12V 100Ah Lifepo4 battery (Min. Order)
Key Company Capacity
Production Capacity >
  • Employees: 501 - 1000 People
  • Factory Size: 10,000-30,000 square meters
  • No. of Production Lines: Above 10
Research & Design >
  • No.of R&D Engineer: 21 - 30 People
  • Production Certification: 4
  • Trademark: 1
Quality Control >
  • No. of In-line QC/QA: 030
Trade Capacity >
  • Export Mode: Have Own Export License
  • Export Percentage: 81% - 90%
  • No. of Employees inTrade Department: Above 50 People
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
TOPBAND/OEM
Model Number:
TB-BL12100F-M110D
Nominal Capacity:
100Ah
Type:
Li-Ion
Weight:
approx.12.2Kg
12V 100Ah Lifepo4 battery Battery type:
LiFepo4 Battery
12V 100Ah Lifepo4 battery Application:
Marine / Caravan
12V 100Ah Lifepo4 battery capacity:
100A
12V 100Ah Lifepo4 battery Life cycle:
2000 times at 100% DOD
12V 100Ah Lifepo4 battery Casing:
ABS case
12V 100Ah Lifepo4 battery dimension:
318x165x215mm
12V 100Ah Lifepo4 battery MOQ:
50pcs
12V 100Ah Lifepo4 battery Lead time:
10-35 working days
12V 100Ah Lifepo4 battery Warranty:
2 years
12V 100Ah Lifepo4 battery Certification:
CE,Rohs,UN38.3,ISO/TS
Application:
Marine / Caravan
Voltage:
12.8V
Size:
318*165*215mm
Composed Type:
4S4P
Components:
LiFePO4 Battery
Supply Ability
Supply Ability:
160000 Piece/Pieces per Month 12V 100Ah Lifepo4 battery
Packaging & Delivery
Packaging Details
12V 100Ah Lifepo4 battery international shipping packing or customize
Port
Shenzhen
Lead Time :
10-30days based on order qty

TOPBAND 12V 100Ah Lifepo4 battery for Marine / Caravan

12V 100Ah Lifepo4 battery Features:

1. Long life, large capacity and good shock resistance

2. Low self-discharge and good discharge performance at low temperature

3. Strong charging acceptance and quick-charging capability

4. Strong over-discharge resistance and charge retention

5. Maintenance-free and no acid or water for maintenance in usage

6. Excellent large current discharge performance, and have obvious advantages in startup and climbing

7. High temperature performance

8. Environmental friendly

9. Lighter weight smaller size

10. Most safe no explosion no fire



12V 100Ah Lifepo4 battery Basic characteristic:

1Nominal Voltage12.8V
2Norminal Capacity100Ah
3Internal Resistanceless than 20mΩ
4Battery operation temperature range @charging0~45C
5Normal charge voltage14.6V
6

Recommended float charge voltage

(for Standby use)

13.9V
7Allowed Max charge current80A@Battery initial Temp 25C
8Recommended charge currentless than 60A
9Battery operation temperature range @discharging-20~60C
10Output Voltage Range8.0~14.6V
11Allowed discharge current100A withstand 30min @Battery initial Temp 25C
12Pulse discharge current350A withstand 3s
13Discharge Cut-off voltage8.0V
14Dimension

Length 318mm

Width  165mm

Height  215mm

15WeightApprox. 12.2Kg



 12V 100Ah Lifepo4 battery application



Service By Us:

  1. Give you the specific battery pack within 24hours according to your requirements
  2. One-stop battery solution with battery cells,PCM,BMS,casing
  3. Prompt settlement of all the problem of our products by our over 14years experienced R&D and advanced producing machine.

Our factory:

Found in 1996,Shenzhen Topband Co.,Ltd(stock code:002139) has been the leading manufacturer of one-stop electronic products in China.There are over 100 R&D engineers and about 4,000 employees in the 75,000 square meters Topband industrial park.

  • Quality System:Passed the HSPM QC080000, ISO14001: 2004, ISO9001: 2000, OHSA28001: 2001,TS16949.
  • Certifications:UL,FCC,ETL,CE,RoHS.
  • Cooperation Association: “Tsinghua University Institute” & “Harbin Industrial University”
  • First-class Workshops and Equipments
  • Over 14years experience staff
  • Above 700,000 square meters factory with more than 3000 staff
  • The largest domestic production based on ERP SAP&PDM, which can completely meet the requirements of large-scale production and ensure good quality of each product
  • A provincial 300 R & D center of technology, a national laboratory and a group of professional people with great experience, skills and qualities
